Inspired from this answer and my comment to it, I seek alternative ways to establish $\pi>3.14$. The goal is to achieve simpler/easy to understand approaches as well as to minimize the calculations involved. The method in my comment is based on Ramanujan's series $$\frac{4}{\pi}=\frac{1123}{882}-\frac{22583}{882^{3}}\cdot\frac{1}{2}\cdot\frac{1\cdot 3}{4^{2}}+\frac{44043}{882^{5}}\cdot\frac{1\cdot 3}{2\cdot 4}\cdot\frac{1\cdot 3\cdot 5\cdot 7}{4^{2}\cdot 8^{2}}-\dots\tag{1}$$ This is quite hard to understand (at least in my opinion, see the blog posts to convince yourself) but achieves the goal of minimal calculations with evaluation of just the first term being necessary.

On the other end of spectrum is the reasonably easy to understand series $$\frac\pi4=1-\frac13+\frac15-\cdots\tag2$$ But this requires a large number of terms to get any reasonable accuracy. I would like a happy compromise between the two and approaches based on other ideas apart from series are also welcome.


A previous question of mine gives an approach to estimate the error in truncating the Leibniz series $(2)$ and it gives bounds for $\pi$ with very little amount of calculation. However it requires the use of continued fractions and proving the desired continued fraction does require some effort.


Another set of approximations to $\pi$ from below are obtained using Ramanujan's class invariant $g_n$ namely $$\pi\approx\frac{24}{\sqrt{n}}\log(2^{1/4}g_n)\tag{3}$$ and $n=10$ gives the approximation $\pi\approx 3.14122$ but this approach has a story similar to that of equation $(1)$.

  • 2
    Probably not what you are looking for. Machin's formula becomes accurate enough with a modest number of terms. Even the series of $\arctan(1/5)$ converges fast enough. Just trying to narrow down the target :-) – Jyrki Lahtonen Oct 23 '17 at 06:55
  • @JyrkiLahtonen: I am looking for any possible approaches and Machin is welcome. If you can give some details of calculation in an answer that would be great. – Paramanand Singh Oct 23 '17 at 06:57
  • 5
    Why the downvote? If this appears to be a low quality question, please suggest ways to improve. I have not asked too many questions but I do try my best to improve the quality of my questions. – Paramanand Singh Oct 23 '17 at 07:09
  • 3
    Another downvote? Perhaps today is my lucky day to have a good supply of wonderful answers and downvotes too. – Paramanand Singh Oct 23 '17 at 08:17
  • 2
    Have a look at http://www.math.ucla.edu/~vsv/resource/general/integral%20approximations%20to%20pi.pdf – Claude Leibovici Oct 23 '17 at 08:33
  • Thanks for the link @ClaudeLeibovici. Two answers here are based on ideas in that link. – Paramanand Singh Oct 23 '17 at 08:37
  • This is why I did search for more of them. Cheers. – Claude Leibovici Oct 23 '17 at 08:42
  • Would you accept to measure an accurately drawn circle of sufficient size? I admit, I'm a (software) engineer, in case that wasn't obvious ;-). But in the end that is what pi is all about. – Peter - Reinstate Monica Oct 23 '17 at 10:04
  • @Peter A. Schneider Do you want to measure the circumference, or the area, and how do you do that? –  Oct 23 '17 at 10:07
  • BBP series in Base 16 maybe? – Henricus V. Oct 23 '17 at 11:02
  • @DavidMitra: yes I would count it as simple. The proof you gave can be understood easily by anyone who is interested in these topics. And the calculations do need square roots which are doable by hand without significant effort. – Paramanand Singh Oct 23 '17 at 11:21
  • @ProfessorVector Easiest would probably be to measure the cirumference vs. the diameter. Given a sufficient supply of millimeter paper one could also measure the area instead of the circumference. It may not be trivial to measure the length of a circumference without resorting to pi already -- it's easy to produce a drawing of a circle, but measuring the circumference one would ordinarily use a wheel which in this case, if I may say so, would amount to circular reasoning... so it may be easier to count little squares. – Peter - Reinstate Monica Oct 23 '17 at 11:49
  • @PeterA.Schneider: Do you want us to draw a circle and measure it physically? I believe this approach was used historically but I am expecting here a method using mathematical ideas and not exactly involving physical measurements. – Paramanand Singh Oct 23 '17 at 11:51
  • @ParamanandSingh Yes, I want to draw a physical circle and measure it. I understand your question and desire but just thought that with enough diligence one could find robust limits for pi from measurements, and it doesn't get any easier than that. (It does get less laborious, though, with a little math, as always). I admit that this pragmatic approach leaves mathematicians wanting -- after all, what proof do we have that D/r or A/r measurements converge for increasingly large circles? But the pragmatist in me loves the idea that you can actually see pi. – Peter - Reinstate Monica Oct 23 '17 at 11:57
  • @PeterA.Schneider: I must say students would be more than delighted if they are introduced to pi with experiments like the one you describe. It is more interesting than the banal sentence "ratio of circumference to diameter of a circle is constant denoted by $\pi$ and this constant is irrational". But I wonder if this approach is followed anywhere in schools. – Paramanand Singh Oct 23 '17 at 13:27
  • wonderful question with a lot of wonderful answers +1 (as usual)... – tired Oct 23 '17 at 18:26
  • 1
    If there is an easy way to show, say, $\log(\pi)>\frac{103}{90}$, exponentiating gives $e^{\log(\pi)}=\pi>e^\frac{103}{90}$, which proves your inequality with seven terms of the McLaurin series. – Jaume Oliver Lafont Oct 26 '17 at 09:03
  • Exponentiating $log(\frac{\pi}{3})>\frac{83}{1800}$ would take only three terms to prove $\pi>3.14$ – Jaume Oliver Lafont Oct 26 '17 at 10:00
  • Since $3.14^3<31$, any strategy proving $\pi^3>31$ (https://math.stackexchange.com/questions/1610024/proving-pi3-gt-31) immediately proves $\pi>3.14$. – Jaume Oliver Lafont Nov 09 '17 at 12:08

14 Answers14

73

From the elementary inequality $$\frac{\sin x}x\le\frac{2+\cos x}3,$$ we get with $x=\pi/6$ easily $\pi\ge\frac{18}{4+\sqrt{3}}=3.1402\ldots$
Proof of the inequality (elementary, though not obvious): let $$f(x)=\frac{\sin x}{x(2+\cos x)}.$$ In order to prove $f(x)\le\lim_{x\to+0}f(x)$, we prove $f(x)\le f(x/2)$. That follows from $$f(x)=f(x/2)\,\frac{(2+\cos x/2)\cos x/2}{1+2\cos^2 x/2},$$ since with $c=\cos x/2$, we have $$\frac{(2+c)c}{1+2c^2}=1-\frac{(1-c)^2}{1+2c^2}\le1.$$

  • 13
    How did you arrive at (think of) this inequality? I have never seen it even as a part some typical exam/exercise. +1 and this one appears very very simple. – Paramanand Singh Oct 23 '17 at 07:43
  • 7
    Your method of proof is so novel and elegant that I had to comment again. – Paramanand Singh Oct 23 '17 at 08:34
  • 7
    @Paramanand Singh It's certainly not a novel method. I don't remember where I've seen it, but it was more than 20 years ago. One can use it to prove $$\frac{\sin x}x\ge\sqrt[3]{\cos x}$$ for $|x|\le\pi/2$, too. With $x=\pi/6$, this gives $\pi\le\sqrt[6]{972}=3.1473\ldots$ –  Oct 23 '17 at 09:44
  • 3
    (+1) Nice solution, but Huygens' inequality is just an instance of the Shafer-Fink inequality! (thanks for the idea, by the way). – Jack D'Aurizio Oct 23 '17 at 11:31
26

If we consider the Beuker-like integral $$ 0<\int_{0}^{1}\frac{x^8(1-x)^8}{1+x^2}\,dx = 4\pi-\frac{188684}{15015} $$ we get, through partial fraction decomposition and few operations in $\mathbb{Q}$, $$ \pi > \frac{47171}{15015} > 3.14159.$$


Inspired by Professor Vector's brilliant approach, I am adding a further approach.
By the Shafer-Fink inequality we have $\arctan(x)>\frac{3x}{1+2\sqrt{1+x^2}}$ for any $x>0$, hence by evaluating both sides at $x=\frac{1}{\sqrt{3}}$ we get $\pi>\frac{18}{13}(4-\sqrt{3})=3.140237\ldots$ A refinement of the previous inequality is $$\forall x>0,\qquad \arctan(x)>\frac{6x}{1+\sqrt{1+x^2}+2\sqrt{2}\sqrt{1+x^2+\sqrt{1+x^2}}} $$ and the evaluation at $x=\frac{1}{\sqrt{3}}$ produces the sharper bound $$ \pi > \frac{36}{2+\sqrt{3}+4 \sqrt{2+\sqrt{3}}} > 3.1415.$$


Yet another approach. The inequality $\arctan(x)>\frac{5x(21+11x^2)}{105+90x^2+9x^4}$ for any $x\in(0,1)$ comes from the Gauss continued fraction / the Padé approximants for the arctangent function. By replacing $x$ with $\frac{x}{1+\sqrt{1+x^2}}$, then evaluating at $x=\frac{1}{\sqrt{3}}$, we get the nice and tight approximation: $$ \pi > \color{blue}{\frac{5}{601}\left(944-327\sqrt{3}\right)}>3.141592.$$


There is also a nice geometric argument leading to an acceleration of Vieta's formula. Let $PQ$ be a side of a regular $n$-agon inscribed in a unit circle centered at $O$. Let $M$ be the midpoint of the minor arc $PQ$. We may consider the unique parabola through $P,M,Q$ and approximate the area of the circle sector delimited by $P,O,Q$ through $[POQ]$ plus the area of a parabolic segment, $\frac{4}{3}[PMQ]:$

enter image description here

It follows that if $A_n$ is the area of the inscribed $2^n$-agon, we have $$ \pi \geq A_n+\frac{4}{3}\left(A_{n+1}-A_n\right) = \frac{4}{3}A_{n+1}-\frac{1}{3}A_n $$ with $$ A_n = 2^{n-1} \sin\frac{\pi}{2^{n-1}} $$ and $\{A_n\}_{n\geq 2}$ being computable through a simple recursion, $$ A_{n+1} = 2^n \sqrt{\frac{1-\sqrt{1-\frac{A_n^2}{4^{2n-2}}}}{2}}$$ where $$ \frac{4}{3}A_5-\frac{1}{3}A_4 = \frac{4}{3}\left[8\sqrt{2-\sqrt{2+\sqrt{2}}}-\sqrt{2-\sqrt{2}}\right]=\color{green}{3.141}44\ldots $$ By considering a $12$-agon and a $24$-agon we get the simpler $$ \pi > 4\sqrt{2}(\sqrt{3}-1)-1 = \color{green}{3.141}10\ldots $$

Jack D'Aurizio
  • 353,855
  • 9
    How many integrals are stored in your memory?? :) I believe the integral gets evaluated easily by expressing integrand as a polynomial + a rational function. +1 – Paramanand Singh Oct 23 '17 at 07:32
  • 1
    The approximation $(18/13)(4-\sqrt{3})$ is good enough and matches the one given by Professor Vector but you get it through a different inequality. The more amazing aspect is that you have a refinement also!! Your last inequality for $x=1$ gives the desired conclusion $\pi>3.14$ – Paramanand Singh Oct 23 '17 at 11:36
  • @Paramanand Singh It's not a different inequality: with $x=\tan\theta$, it becomes the same after a few simple steps. –  Oct 23 '17 at 12:02
  • @ProfessorVector: I was not claiming otherwise, Huygens' inequality is an instance of the Shafer-Fink inequality. In any case, I have just added a further approach based on Padé approximants. – Jack D'Aurizio Oct 23 '17 at 12:22
  • 3
    Don't know what to say now. Looks like you have $n$ number of weapons in your arsenal where $n\to\infty$ with growing time. – Paramanand Singh Oct 23 '17 at 13:23
  • 3
    Coming home from work and observing that my favorite moderator has already presumptuously used both approaches i could imagine to answer this wonderful question is really frustrating. (+1) for sure! – tired Oct 23 '17 at 18:25
  • 2
    A small change to your first integral gets the precision of your last approach: $$\frac{\sqrt{3}}{27}\int_0^1 \frac{x^8(1-x)^8}{1+x+x^2}dx = \pi - \frac{17647759\sqrt{3}}{9729720}$$ – Jaume Oliver Lafont Oct 25 '17 at 22:36
  • @JaumeOliverLafont: interesting observation, thank you. – Jack D'Aurizio Oct 25 '17 at 22:42
  • The parabolic segment approximation can be found buried deep in this absurdly long answer of mine from last year. (I promised to add a third addendum, tidying up the mess I made of the accelerated Viete's formula, but the method of exhaustion lived up to its name, and I was too tired to bother!) Is there a 'proper' published source somewhere? (I dimly recall that user5713492's comments may have led me to some relevant classical work by Huygens or Snell.) – Calum Gilhooley Aug 27 '18 at 14:37
  • @CalumGilhooley: I also noticed that the accelerated Vieta's formula, Huygens' inequality and the Shafer-Fink inequality rely on the very same ground, but I honestly do not know if this observation has been published somewhere. – Jack D'Aurizio Aug 27 '18 at 14:46
21

Take Machin's formula: $$\pi=16\tan^{-1}\frac15-4\tan^{-1}\frac1{239}$$ Expand the arctangents into their Taylor series: $$\pi=16\left(\color{blue}{\frac15-\frac1{5^3×3}}+\frac1{5^5×5}-\dots\right)-4\left(\color{blue}{\frac1{239}}-\frac1{239^3×3}+\dots\right)$$ $$=\color{blue}{\frac{16}5-\frac{16}{375}-\frac4{239}}+\delta$$ $$=\color{blue}{3.140596\dots}+\delta$$ with $0<\delta<\frac{16}{5^5×5}+\frac4{239^3×3}$ since the two series are alternating with term magnitudes strictly decreasing. This proves $\pi>3.140596\dots>3.14$.

Parcly Taxel
  • 103,344
  • This meets both the criteria : formula is simple to understand and calculations are also easy (doable by hand within minutes). +1 Will wait for more answers before accepting any. – Paramanand Singh Oct 23 '17 at 07:28
12

Similarly to Jack d'Aurizio's answer (first section), we have the simpler integral

$$\frac{1}{2}\int_0^1 \ \frac{x^3(1-x)^6}{1+x^2} dx = \pi-\frac{1759}{560}=\pi-\left(3.14+\frac{3}{2800}\right)$$

A similar one evaluating to exactly $$\pi-3.14=\pi-\frac{157}{50}$$ can be obtained with the methods of Lucas (http://educ.jmu.edu/~lucassk/Papers/more%20on%20pi.pdf)

Since

$$3.14=\frac{157}{50}=\frac{22}{7}-\frac{1}{350},$$

the result can be obtained subtracting Dalzell's integral

$$\int_0^1 \frac{x^4(1-x)^4}{1+x^2}dx =\frac{22}{7}-\pi$$

from $$\frac{4}{5}\int_0^1 x^3(1-x)^4 dx = \frac{1}{350},$$

which gives

$$\frac{1}{5}\int_0^1 \frac{x^3(1-x)^4(4-5x+4x^2)}{1+x^2} dx = \pi -\frac{157}{50} > 0 $$

This is a direct proof for $\pi>\frac{157}{50}$ because the integrand is non-negative in $(0,1)$, very close to this proof that $\frac{22}{7}$ exceeds $\pi$.

The corresponding series is

$$1152\sum_{k=0}^\infty \frac{2k^2+8k+13}{(4k+4)(4k+5)(4k+6)(4k+7)(4k+9)(4k+10)(4k+11)(4k+12)}=\pi-\frac{157}{50}$$

(check


We can also take the first term out of a series relating $\pi$ with the approximation from below $\frac{25}{8}$ to get

$$\begin{align} \pi &= \frac{25}{8} + \sum_{k=0}^\infty \frac{360}{(4k+2)(4k+4)(4k+5)(4k+7)(4k+8)(4k+10)}\\ &=\frac{1759}{560} + \sum_{k=1}^\infty \frac{360}{(4k+2)(4k+4)(4k+5)(4k+7)(4k+8)(4k+10)}\\ \end{align}$$

where $\frac{1759}{560}>3.14$ as shown above.

This fraction already appeared in the first integral, but proving the series as in this answer now gives

$$\frac{1}{4}\int_0^1 \frac{x^5(1-x)^4(1+4x+x^2)}{1+x^2}dx = \pi -\frac{1759}{560}$$

11

For modest requirements of accuracy, we can use a quite basic and easy to understand convergence acceleration technique to transform the Gregory/Leibniz series into something that yields the result with little computation.

If we have an alternating series

$$\sum_{n = 0}^{\infty} (-1)^n a_n$$

where the $a_n$ are slowly converging to $0$, then it takes little guessing to believe that the arithmetic mean of two successive partial sums of the series is a much better approximation to the value of the series than either or the two partial sums. We can write the mean as

$$\sum_{n = 0}^{m-1} (-1)^n a_n + \frac{(-1)^m a_m}{2} = \frac{a_0}{2} + \frac{1}{2} \sum_{n = 0}^{m-1} (-1)^n(a_n - a_{n+1})$$

and see that if $\bigl(a_n - a_{n+1}\bigr)_{n\in \mathbb{N}}$ is a decreasing sequence we immediately have an error bound of $\frac{1}{2}(a_{m} - a_{m+1})$ for this arithmetic mean. If $(a_n)$ is slowly converging, then this is much smaller than either of $a_m$ and $a_{m+1}$. For nice $(a_n)$, this can be iterated.

If we apply that to $a_n = \frac{1}{2n+1}$, we find $a_n - a_{n+1} = \frac{2}{(2n+1)(2n+3)}$, which is decreasing - and still converges slowly to $0$, so we get a significant improvement from then applying the method again. We get

\begin{align} \frac{\pi}{4} &= \sum_{n = 0}^{\infty} \frac{(-1)^n}{2n+1} \\ &= \frac{1}{2} + \sum_{n = 0}^{\infty} \frac{(-1)^n}{(2n+1)(2n+3)} \\ &= \frac{1}{2} + \frac{1}{6} + 2\sum_{n = 0}^{\infty} \frac{(-1)^n}{(2n+1)(2n+3)(2n+5)} \\ &= \frac{1}{2} + \frac{1}{6} + \frac{1}{15} + 6\sum_{n = 0}^{\infty} \frac{(-1)^n}{(2n+1)(2n+3)(2n+5)(2n+7)} \end{align}

and so on, each series converging faster than the previous. Since the terms get more complicated, it is computationally - at least when done by hand - better to start accelerating not right at the beginning of the series, but rather compute a partial sum of the original series, and then use acceleration only on the remainder. Let's say that starting the remainder at $n = 4$ wouldn't need an unreasonable amount of computation, then we get

\begin{align} \frac{\pi}{4} &= 1 - \frac{1}{3} + \frac{1}{5} - \frac{1}{7} + \sum_{n = 4}^{\infty} \frac{(-1)^n}{2n+1} \\ &= 1 - \frac{1}{3} + \frac{1}{5} - \frac{1}{7} + \frac{1}{18} + \sum_{n = 4}^{\infty} \frac{(-1)^n}{(2n+1)(2n+3)} \\ &= 1 - \frac{1}{3} + \frac{1}{5} - \frac{1}{7} + \frac{1}{18} + \frac{1}{198} + 2\sum_{n = 4}^{\infty} \frac{(-1)^n}{(2n+1)(2n+3)(2n+5)} \\ &= 1 - \frac{1}{3} + \frac{1}{5} - \frac{1}{7} + \frac{1}{18} + \frac{1}{198} + \frac{1}{1287} + 6\sum_{n = 4}^{\infty} \frac{(-1)^n}{(2n+1)(2n+3)(2n+5)(2n+7)} \\ &> 1 - \frac{1}{3} + \frac{1}{5} - \frac{1}{7} + \frac{1}{18} + \frac{1}{198} + \frac{1}{1287} \\ &> 0.78519 \end{align}

and thus $\pi > 3.14076$.

Of course Machin-like formulæ are far more efficient. But it's not too terrible.

Daniel Fischer
  • 206,697
8

Another simple method is to use the Newton-Raphson method to find the zero of the function $\sin(x)$ at $x = \pi$ using the initial guess of $x = 3$. The fact that at $x = \pi$ the function $\sin(x)$ has a point of inflexion, means that convergence to $x = \pi$ will happen in an alternating way, therefore you obtain rigorous upper and lower bounds. So, the sequence defined by the recurrence:

$$x_{n+1} = x_n - \tan(x_n)$$

and $x_0 = 3$ converges to $\pi$. We have $x_1 = 3.1425\cdots$, $x_2 = 3.1415926533\cdots$, and therefore $\pi > 3.1415926533$. Now, we need to compute $x_2$ here without using $\pi$ itself, we can use the series expansions of $\sin(x)$ and $\cos(x)$ around $x = 0$. These are both alternating series, so we can easily get to an accurate bound on $x_1$ and from that we can get to an accurate bound on $x_2$, the lower bound of which then yields an accurate lower bound for $\pi$.

Count Iblis
  • 10,366
  • 3
    If the goal is just to compare $3.14$ to $\pi$, it's even faster to start the iteration at $x_0=3.14$ and simply see which way it moves. Then we don't even need to compute the cosine in the denominator, because we know already what its sign will be. – hmakholm left over Monica Oct 23 '17 at 14:40
  • 1
    In fact, the quadratic convergence of Newton-Raphson ought to hold even if we replace $f'(x_n)$ in the recurrence with $f'(x_{\rm root})$ (which in this case we happen to know exactly), so we can iterate $x\mapsto x + \sin x$ instead and save a series evaluation and a long division in each step. The convergence will then not be alternating, but we can still get a bound from the opposite side as $x_{n-1}+2\sin x_{n-1}$, since as soon as we're even slightly close we know $f'(x_n)\in [-1,-\frac12)$. – hmakholm left over Monica Oct 23 '17 at 14:55
6

Since $\cos \frac\pi3 = \frac12$ and the cosine is strictly decreasing between $0$ and $\pi$, we can prove that $3.14 < \pi$ by showing that $\cos\frac{3.14}3 > \frac12$. This takes only 4 terms of the power series for cosine:

x^0/0! = 1   adding gives 1
x^2/2! = 0.547755555555556   subtracting gives 0.452244444444444
x^4/4! = 0.0500060247736625   adding gives 0.502250469218107
x^6/6! = 0.00182607185873483   subtracting gives 0.500424397359372

Since the series is alternating and absolutely decreasing, when we have just subtracted a term and gotten something above $\frac12$ we now know that the limit is larger than $\frac12$.

Edit: showing that $\sin\frac{3.14}6 < \frac12$ is slightly faster:

x^1/1! = 0.523333333333333   adding gives 0.523333333333333
x^3/3! = 0.0238882283950617   subtracting gives 0.499445104938272
x^5/5! = 0.000327122745394376   adding gives 0.499772227683666

One can do this with pen and paper, keeping 4 digits after the decimal point in every intermediate (and explicit interval arithmetic), using just two 4-by-4 multiplications and two 4-by-3 to show $3.141<\pi$:

handwritten calculation

Five terms to 10 decimal digits will show that $3.14159 < \pi < 3.14160$.

  • 2
    The arctan series has become so popular that one misses the usual series for sine / cosine. Very direct and simple approach +1 – Paramanand Singh Oct 23 '17 at 13:18
  • OMG!! Indisputable proof that it is calculated via hand :) :) however I was convinced by your earlier version too. – Paramanand Singh Oct 24 '17 at 03:28
  • In my high school days when there was no computer / internet and calculator could give only 10 digits, I used lot of paper to get hold of digits of $e$(simple) and $\pi$(not so simple). Got reminded of those days with your answer. – Paramanand Singh Oct 24 '17 at 03:33
5

A very easily understandable way is to use regular polygons inscribed into a circle of radius $1$. If $a_n$ is the length of the side of the $n$-gon, then $$a^2_{2n} = 2-\sqrt{4-a^2_n}\text{.}$$  A lower bound on $a_n$ implies a lower bound on $a_{2n}$, we can thus round down intermediary results. Four applications of the formula with 4 to 5 significant digits are enought to establish the bound of $3.14$. $$\begin{array}{rl} a^2_6 =& 1\\ a^2_{12} >& 0.2679 \\ a^2_{24} >& 0.06813 \\ a^2_{48} >& 0.017105 \\ a^2_{96} >& 0.004280 \\ \end{array}$$ Leading to $a_{96} > 0.06542$ and $\pi > 48a_{96} > 3.14$.

  • This is the approach given by David Mitra in comments to my question. His linked answer contains more details. But since you added it here on your own +1 for you. – Paramanand Singh Oct 23 '17 at 11:55
  • 3
    This is basically how Archimedes showed $\pi > 3+\frac{10}{71}$. – Sil Oct 23 '17 at 11:56
4

This is a slight variant on Henning Makholm's answer, with an emphasis on actually carrying out the computations that are required to verify the desired inequality.

Let $u=.314$. It suffices to show that $\sin u\lt\sin\left({\pi\over10}\right)={\sqrt5-1\over4}$. But

$$\sin u\lt u-{u^3\over6}+{u^5\over120}\lt u\left(1-{u^2\over6}+\left({u^2\over6}\right)^2\right)$$

At this point it's not too hard to get a calculator to tell you that

$$.314\left(1-{.314^2\over6}+\left(.314^2\over6\right)^2\right)\approx0.3089249\lt.309017\approx{\sqrt5-1\over4}$$

but let's do it showing (almost) all the arithmetic to establish the inequalities

$$.314\left(1-{.314^2\over6}+\left(.314^2\over6\right)^2\right)\lt.309\lt{\sqrt5-1\over4}$$

The second inequality is equivalent to $2.236\lt\sqrt5$. Since $2236/4=559$, this is equivalent to $559^2\lt5\cdot250^2=312500$. It's not too hard (especially if you use a calculator...) to compute $559^2=312481$, which verifies the inequality. (Note, I consider $5\cdot25^2=5\cdot625=3125$ to be an "easy" multiplication.)

As for the first inequality, since $.309=.314-.005$, it is equivalent to

$${.314^2\over6}-\left(.314^2\over6\right)^2\gt{5\over314}$$

The (not too hard) computation $314^2=98596$ followed by division by $6$ shows that

$$.0164\lt{.314^2\over6}\lt.02$$

It follows that

$${.314^2\over6}-\left(.314^2\over6\right)^2\gt.0164-.0004=.016={16\over1000}={2\over125}\gt{5\over314}$$

where the final inequality is verified by $2\cdot314=628\gt625=5\cdot125$.

If there is an easier way to organize the arithmetic so that you don't have to do a couple of messy multiplications (e.g., $559\times559$ and $314\times314$) somewhere along the line, I'd like to see it. (Even Professor Vector's marvelous answer, when ${18\over4+\sqrt3}\gt3.14={157\over50}$ is simplified to the inequality $900-628=272\gt157\sqrt3$, seems to require computing $272^2$ and $157^2$.)

Barry Cipra
  • 79,832
  • 1
    Since 3.14 already has 3 significant digits, I think it is not unreasonable to need some arithmetic on numbers of that size. Computing 3 terms of $\sin (3.141/6)$ with a precision of $10^{-4}$ in every intermediary requires two 4-by-4 multiplications and two 4-by-3, hardly onerous even with pencil and paper. – hmakholm left over Monica Oct 23 '17 at 21:45
3

From $$\pi=\sum_{k=0}^{+ \infty}{\dfrac {1}{16^k}} \cdot \dfrac {120k^2+151k+47}{512k^4+1024k^3+712k^2+194k+15}$$ you obtain your inequality by summing just the first two terms.

  • The formula used here is the famous Bailey-Borwein-Plouffe formula which can be proved using integrals. – Paramanand Singh Oct 24 '17 at 03:57
  • @ParamanandSingh Yes, maybe this is not in the category of simplest approaches, but, as you see, if we discard addition in the calculation of digits, then there are only two divisions to perform. –  Oct 24 '17 at 12:16
  • And all the terms are strictly positive so that guarantees us that only the first two steps are needed. –  Oct 24 '17 at 12:19
  • I am aware of the proof of BBP and the proof is not difficult (integral evaluation of a rational function) so I am counting it as simple. And +1 has been delivered to you already. :) – Paramanand Singh Oct 24 '17 at 17:14
  • @ParamanandSingh Haha thanks, I would also like to mention that this approach with BBP is probably more simple then yours with Ramanujan´s formula because if that formula alternates with + and - signs there is also a need to show that only the first term suffices, that is, that the negative terms will not take over some decimals. –  Oct 24 '17 at 17:17
  • Yes that is one aspect with any alternating series. One needs to show that the terms are decreasing in absolute value. But more importantly Ramanujan series in my question is so so hard to establish manually. Borwein brothers (who proved these series) mentioned that the parameters (the number $1123$ in this series) for the series were evaluated numerically and then using some algebraic properties of these parameters (based on class field theory and what not) it was established that the parameters must have the value which are mentioned by Ramanujan. – Paramanand Singh Oct 24 '17 at 17:25
  • @ParamanandSingh I do not understand all of what you mention but I am interpreting it in the sense that this series of Ramanujan is unique in some very precise definition of "uniqueness". –  Oct 24 '17 at 17:32
  • I have given some details about the way these parameters of such series are evaluated in this answer: https://math.stackexchange.com/questions/14115/motivation-for-ramanujans-mysterious-pi-formula/434237#434237 – Paramanand Singh Oct 24 '17 at 20:15
2

Equation (2) in the question is the result of plugging $x=1$ in the expansion for the arctangent, using

$$\frac{\pi}{4}=\tan^{-1}(1)$$

Instead, from $$\frac{\pi}{6}=\tan^{-1}\left(\frac{1}{\sqrt{3}}\right)$$ a series with faster convergence is obtained. Taking six terms,

$$\pi>2\sqrt{3}\left(1-\frac{1}{3·3}+\frac{1}{5·3^2}-\frac{1}{7·3^3}+\frac{1}{9·3^4}-\frac{1}{11·3^5}\right)=\frac{509024\sqrt{3}}{280665}>3.141$$

Four terms from $$\frac{\pi}{8}=\tan^{-1}\left(\sqrt{2}-1\right),$$ give

$$\pi> 8\left(\sqrt{2}-1-\frac{(\sqrt{2}-1)^3}{3}+\frac{(\sqrt{2}-1)^5}{5}-\frac{(\sqrt{2}-1)^7}{7}\right)=\frac{32}{105}\left(716-499\sqrt{2}\right)>3.141,$$

while two terms from $$ \frac{\pi}{12}=\sin^{-1}\left( \frac{\sqrt{3}-1}{2\sqrt{2}} \right)$$

lead to $$\pi > 12\left( \frac{\sqrt{3}-1}{2\sqrt{2}} + \frac{1}{6} \left(\frac{\sqrt{3}-1}{2\sqrt{2}}\right)^3 \right) = \frac{27\sqrt{3}-29}{4\sqrt{2}}>3.14$$

2

From series $$\pi^6=960\sum_{k=0}^\infty \frac{1}{(2k+1)^6},$$

$$\pi^6>960$$

But $3.14^6<960$, so $3.14^6<\pi^6$ and therefore $3.14<\pi$.

1

Do you want a solution that is a compromise between calculation efficiency and ease of understanding? This story might help.

Many, many years ago in school, I was introduced to Fortran and had limited access to a computer. It was physically large but very low power by today's standards. I knew the famous $\frac{\pi}{4} = \tan^{-1}(1)$ formula but I also realised how slowly it converges. I would not be able to get far with the run time available to me.

The internet did not exist yet and the school's and the local public library did not help. I knew how the $\frac{\pi}{4}$ was derived so I played with other trig formulae. I managed to calculate the Taylor series of $\sin^{-1}$ by a mixture of messy differentiation and induction. I figured that if I evaluated $\frac{\pi}{6} = \sin^{-1}(\frac{1}{2})$, the convergence would be linear: twice the terms would give me twice the number of decimal places. In practice, the algorithm was quadratic since if I aimed at $n$ times as many decimal places, I would need $n$ times as many terms and each calculation would take $n$ as long.

I forget the run time that I had but the best I achieved was 500 decimal places.

Many years later but still long ago, I rewrote the program in C and ran it on an idle Unix system at work. In a month, it calculated a million decimal places. For comparison, I ran it on my laptop a few years ago, a million places took 3.5 hours. My Raspberry Pi required 44 hours.

badjohn
  • 8,204
  • As evident from my question as well as other answers here, what I seek is a method to show that $\pi>3.14$. The method should involve as minimal calculations as possible as well as should be based on mathematical ideas which are easy to understand. What you describe in your story is more related to evaluating million digits of $\pi$ and how technology has helped reduce the time needed to get those digits. While I agree with the facts in your story, it does not really give an answer to my question. – Paramanand Singh Oct 24 '17 at 09:38
  • My objective was to calculate as many digits as possible but it could also be used for your objective. It is easy to show that the partial sums are alternating over and under estimates. So, you can stop once you find that the lower estimate has exceeded $3.14$. This may not be the most efficient solution but I thought that you wanted one that was easy to understand. I figured this out when I was 16 at school so I think that it qualifies as easy to understand. – badjohn Oct 24 '17 at 10:14
  • Yeah it qualifies as very easy to understand and I mentioned the Leibniz series for $\pi/4$ in my question. The trouble is that it takes a reasonably large number of terms to reach desired level of accuracy. – Paramanand Singh Oct 24 '17 at 11:56
  • That's the point of my solution. You need far fewer terms, it is linear: twice as many terms gives you twice as many decimal places. I forget now but I think that it was around 1.6 terms per dp, certainly less than 2. So, 4 or 5 terms would probably be enough. You would not even need my induction step to calculate the $n$th derivative, just calculate the first few long hand. – badjohn Oct 24 '17 at 12:07
  • From asin(1/2) I get underestimates only and four terms suffice: $$\pi>6\left(\frac{1}{2}+\frac{1}{6·2^3}+\frac{3}{40·2^5}+\frac{5}{112·2^7}\right)= \frac{56327}{17920}>3.141$$ – Jaume Oliver Lafont Oct 26 '17 at 14:32
  • @JaumeOliverLafont Thanks. I should have checked rather than rely on a decades' old memory. That all terms are positive makes it even simpler. However, the key point of my story is that I figured this out in school when calculus was a very new subject to me. I would have been 16 or 17 at the time. – badjohn Oct 27 '17 at 09:14
1

Approach-1: Using basic geometry (This method is inspired by Archimedes method to estimate $\pi$)

Draw a circle of radius 'r' .

Now, draw a regular polygon (say, polygon-1) with '$N_c$' number of sides such that the circle is circuim-cicle to this polygon. Also, draw another regular polygon (say, polygon-2) with '$N_i$'number of sides such that the circle is in-circle to this polygon.

So,perimeter of Polygon-1 is equal to $C_1=2rN_c sin(\frac{\pi}{N_c})$

Also, it can be found that perimeter of Polygon-2 is equal to $C_2=2rN_i tan(\frac{\pi}{N_i})$

If 'C' is the circumference of the circle, then we know that, $C=2r\pi $

So, by using the fact that 'the sum of any two two sides of a triangle is always grater than the third side' , we can easily show that $C_1<C<C_2$ Putting values, we find that, $2rN_c sin(\frac{\pi}{N_c})<2r\pi<2rN_i tan(\frac{\pi}{N_i})$

This simplifies as, $N_c sin(\frac{\pi}{N_c})<\pi<N_i tan(\frac{\pi}{N_i})$ .......(1)

So, for any two assumed positive values of $N_c$ and $N_i$ , the relation (1) is always valid and is satisfied. As we can observe easily, if $N_c$ and $N_i$ gets infinitely larger, then both polygons-1 & 2 as mentioned above approximates the circle of radius 'r'more closely.

Let, $N_c=N_i=N$ , then it can be proved very easily that, $ \lim_{{N}\to{\infty}} Nsin(\frac{\pi}{N})=\pi$ and $ \lim_{{N}\to{\infty}} Ntan(\frac{\pi}{N})=\pi$

So, inequality (1) is the simplest way to get lower and upper bounds for $\pi$ and these bounds can be improved as per our choice of values of$N_c$ and $N_i$ as per above discussion.

For example. $N_c=N_i=N=4$ gives a bound as, $4 sin(\frac{\pi}{4})<\pi<4 tan(\frac{\pi}{4})$ i.e. $2\sqrt{2} <\pi<4 $

Also, if we increase $N$ to $N_c=N_i=N=6$ , we get a bound as, $6 sin(\frac{\pi}{6})<\pi<6 tan(\frac{\pi}{6})$ i.e. $3 <\pi<2\sqrt{3} $ which is a more tighter bound and so on. It can be found numerically that, when N>57, we have $3.14 <\pi $

Also, if $N_c=6 , N_i=4$ then, using the inequality $N_c sin(\frac{\pi}{N_c})<\pi<N_i tan(\frac{\pi}{N_i})$ , we find that $6 sin(\frac{\pi}{6})<\pi<4 tan(\frac{\pi}{4})$ i.e.$ 3<\pi<4 $

So, $\pi$ can be approximated as the average of these limits as $N_c,N_i\to\infty$

Approach-2: Riemann Zeta function:

We know a well known and famous relation that was given by Euler that,

if 'n' is a positive integer and if $\zeta(2n)=\frac{1}{1^{2n}}+\frac{1}{2^{2n}}+\frac{1}{3^{2n}}+\frac{1}{4^{2n}}+.....$ then, $\zeta(2n)=(-1)^{n+1}\frac{B_{2n}2^{2n-1}\pi^{2n}}{(2n)!}$

Separating $\pi$ from this relation, we get $\pi^{2n}=\frac{(2n)!\zeta(2n)}{(-1)^{n+1}B_{2n}2^{2n-1}}$

So, $\pi=(\frac{(2n)!\zeta(2n)}{(-1)^{n+1}B_{2n}2^{2n-1}})^{\frac{1}{2n}}$

As it can be observed easily that $\lim_{{n}\to{\infty}}\zeta(2n)=1$ Hence it can be concluded that $\pi=\lim_{{n}\to{\infty}}(\frac{(2n)!}{(-1)^{n+1}B_{2n}2^{2n-1}})^{\frac{1}{2n}}$

Since $\sum_{r=1}^{k}\frac{1}{r^{2n}}<\zeta(2n)$ , hence $\pi>(\frac{(2n)!\sum_{r=1}^{k}\frac{1}{r^{2n}}}{(-1)^{n+1}B_{2n}2^{2n-1}})^{\frac{1}{2n}}$

Actual application of this relationship is quite computationally time consuming but it's really a good approximation when 'n'and 'k' are fairly high values (even $n>8$ and $k>10 $ will give a reasonably good and closer higher bound for $\pi$)
